Starlink V3

KEY FEATURES

Starlink Antenna

• Type: Electronic Phased Array
• Field of View: 110°
• Orientation: Software-Assisted Manual Orienting
• Weight: 2.9 kg (6.4 lb); 3.2 kg (7 lb) with Kickstand
• Environmental Rating: IP67 Type 4
• Operating Temperature: -30°C to 50°C (-22°F to 122°F)
• Wind Speed: Operational at 96 kph+ (60 mph+)
• Snow Melt Capability: Up to 40 mm/hour (1.5 in/hour)
• Power Consumption: 75 – 100 W (Average)

WiFi Router (Gen 3)

• Product Dimensions: 43.4 x 298.6 x 120.4 mm (1.7 in x 11.76 in x 4.74 in)
• Wi-Fi Technology: 802.11 a/b/g/n/ac/ax (Wi-Fi 6)
• Radio: Tri-Band 4×4 MU-MIMO
• Ethernet Ports: Two (2) Latching Ethernet LAN ports with removable cover
• Coverage: Up to 297 m² (3,200 ft²)
• Operating Temperature: -30°C to 50°C (-22°F to 122°F)
• Weight: 0.57 kg (1.25 lbs)
• Security: WPA2
• Environmental Rating: IP56 (Water Resistant)
• Power Indicator: LED on face plate, lower left corner
• Mesh Compatibility: Supports Starlink Gen 2 and Gen 3 Mesh Nodes (up to 3 nodes)
• Device Capacity: Connects up to 235 devices

Power Supply

• Product Dimensions: 173 x 93 x 35.75 mm (6.8 in x 3.66 in x 1.4 in)
• Weight: 0.65 kg (1.43 lbs)
• Environmental Rating: IP66 Type 4
• Operating Temperature: -30°C to 60°C (-22°F to 140°F)
• Power Specifications: 100-240V ~ 2.5A, 50 – 60 Hz

What’s in the Box

• Starlink Gen 3 Antenna
• Kickstand
• Gen 3 Router
• Starlink Cable (15 m / 49.2 ft)
• AC Cable (1.5 m / 4.92 ft)
• Power Supply (1.5 m / 4.92 ft)

Gen 3 Router vs Previous Versions

• Improvements:
  • Wi-Fi 6 chipset for faster speeds and better performance in congested environments.
  • Tri-band radios for enhanced mesh performance.
  • Two Ethernet ports and a factory reset button.
• Additional Features:
  • Improved range.
  • Water-resistant port covers.
  • Enhanced signal test via the Starlink App for optimized speeds.
